Description

All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243. All positive, negative and grounding buses installed, fully pre-wired.

Blue Sea 8068BSS Attributes

• Recommended Use: Commercial
• Voltage Rating: 12 Volt
• Power Rating: 50 Amp
• Receptacle Type: No Receptacle
• Number Of Connections: 13
• Length (IN): 10-1/2 Inch
• Width (IN): 7-1/2 Inch
• Height (IN): 3 Inch
• Color: Black
• Material: Metal
• With Flip Cover: No

Blue Sea 8068BSS Features & Benefits

• All Positive, Negative And Grounding Buses Installed, Fully Pre-Wired
• Panels With Meters Include Toggle Switch For Mounting Up To 3 Battery Banks
• All Circuit Label Positions Are Backlit On Standard Panels
• ON Indicating LEDs Installed In All Circuit Positions
• No Supplier Warranty

Blue Sea 8068BSS Installation Instructions

• 9776.pdf

Blue Sea 8068BSS Technical Bulletins

• 9781.pdf

8068 DC 13 Position Toggle Branch Circuit Breaker Panel – White Switches

Features:

• All positive, negative and grounding buses installed, fully pre-wired
• Includes set of 30 common DC labels
• Label backlighting pre-installed
• All LEDs installed
• Detailed installation instructions and cutout template
• 8028, 8-16 Volt DC Micro Voltmeter
• 8041, 0-50 Amp DC Micro Ammeter
• Owner upgradeable to 24 Volts DC with 8243, 10-32 Volt DC Micro Voltmeter
• 10 15A Single Pole Circuit Breakers
• Toggle Branch Circuit Breaker Panel

Specifications:

• Positions: 13
• Nominal Voltage: 12v DC
• Maximum Amperage: 50A
• Height: 7.5″
• Width: 10.5″
• Depth: 3″
• Weight: 4.2 lbs

Included:

• (10) 7210 A-Series White Toggle Circuit Breaker – Single Pole 15A
• (1) 8030 Basic DC Panel Label Set – 30 Labels
• (1) 8028 DC Micro Voltmeter – 8 to 16v DC (Meter)
• (1) 8041 DC Micro Ammeter – 0 to 50A w/ Shunt (Meter)

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

With 13 circuit breaker positions, ten 15a are installed. 8-16 volt voltmeter with 3 position switches for multiple battery packs. 0-50 ampere ammeter with remote shunt. All positive…
SKU: NVN-13971
MPN: 8068-BSS
UPC: 632085080686
